Geary County Sec. 7, T. 12 S., R. 6 E

One mile East of Junction City Measured By M.K. Elias, 1932
	Unit No. Description Thickness   Holmesville Shale Formation   58 Limestone, crystalline (secondary?) 2 ft. 57 Shale, calcareous, chalky   56 Mudstone, geodic 10 ft. 55 Limestone, splittery, with pelecypods 1.5 ft. 54 Shale, clayey 2 ft. 53 Mudstone, splittery, in lower part pelecypods (Pleurophorus) Orbiculoidea, and impressions of sea weed 1.5 ft. 52 Shale, calcareous, in lower part with Derbya, Pinna, and Straparollus 2 ft. 51 Mudstone, splittery, with Derbya, and Linoproductus, throughout; Composita, Allorisma, Pinna, and echinoid remains in lower part 1 ft. 50 Shale, calcareous 0.5 ft.   Fort Riley Limestone Member   49 Limestone, massive, light-gray, with vertical flint veins at the top. Meekella at the top. Throughout the bed small and mostly fragmentary fossils among which can be recognized small crinoid joints, bryozoans, and spines of brachioods. Elsewhere with pelecypods and nautiloid cephalopods 4.5 ft.   Oketa Shale Member   48 Shale, calcareous, with Ambocoelia, and echinoid remians 0.5 ft. 47 Limestone, massive, with Dictyoclostus, and bryozoa, and with Allorisma at the base 2 ft. 46 Shale, calcareous, to mudstone, with Composita, Ambocoelia, Meekella, Bryozoans, Pelecypoda, and Straparollus 5 ft.   Florence Limestone Member   45 massive limetsone and calcareous shale, with flint bands 2.5 ft. 44 Limestone, massive, with flint. Dictyoclostus, Derbya, Myalina, Meekella, stony bryozoa 1.1 ft. 43 Shale, calcareous, with Composita, Derbya, Dictyoclostus 1.8 ft. 42 Limestone, massive with flint partly replacing center, flint bands, Rhombopora 3 ft. 41 Shale, calcareous 0.5 ft. 40 Limestone, with cariably thick, massive flint bands, Rhombopora 13.2 ft. 39 Shale, calcareous 0.2 ft. 38 Limestone with six flint bands. The upper three heavier and distantly spaced, the lower three thinner and close together. Triticites, and Rhombopora in the fifth flint band from the base and between the fifth and sixth bands 4.5 ft.   Blue Springs Shale Formation   37 Shale, calcareous 0.7 ft. 36 Mudstone, somewhat splittery 0.8 ft. 35 Shale, calcareous 0.5 ft. 34 Mudstone. In this and the two higher beds, Dictyoclostus, Composita, and crinoid joints 0.8 ft. 33 Shale, calcareous 0.7 ft. 32 Mudstone, with Juresania, Derbya and Pelecypods 0.4 ft. 31 Shale, dark gray to black Bituminous 0.3 ft. 30 Mudstone, gray, massive 1.9 ft. 29 Shale, cariably colored; green, red, maroon, dark blue 22.5 ft.   Kinney Limestone Formation   28 Mudstone with Derbya, Composita, Juresania, and bryozoa 1 ft. 27 Shale, yellowsh gray 3 ft. 26 Shale, dark bluish-gray, massive 6 ft. 25 Limestone, gray 0.7 ft. 24 Shale, gray at the base calcareous wit Juresania, Hustedia, echinoid remains 8.5 ft. 23 Limestone, tough, buff, with Myalina, and Delto at the top 1.6 ft.   Wymore Shale Formation   22 Shale 0.5 ft. 21 Mudstone 0.5 ft. 20 Shale, calcareous, splitter 1.5 ft. 19 Mudstone, yellowish gray, splittery 2 ft. 18 Shale, somewhat calcareous 1.3 ft. 17 Limestone 0.3 ft. 16 Shale, calcareous, green, maroon, and Limestone, tough, gray, with small gatropods 11.7 ft. 15 Limestone, gary, fossiliferous 2 ft.   Schroyer Limestone Member   14 Limestone with heavy flint band. Large Derbya at the top 1 ft. 13 Covered 45.5 ft. 12 Limestone, tough, light-gray, cavernous, few fossils 1 ft. 11 Shale, green, maroon, purple 6.1 ft. 10 Mudstone, light green 1.9 ft. 9 Shale, maroon 0.5 ft. 8 Mudstone, light-green 2 ft. 7 Shale, green calcareous with Juresania, banded 14 ft. 6 Mudstone, greenish-gray 1 ft. 5 Shale, green, maroon, calcareous, blue-green 3.2 ft. 4 Mudstone, light green 1.8 ft. 3 Shale, calcareous, blue-green, maroon, green 4.6 ft. 2 Mudstone, gray, flaggy 3 ft. 1 Shale, calcareous, gray, black, splittery, with Orbiculoidea 2 ft.
Original Document Download an archival scan (file is 4-5 megs in size). The Archive file you download contains a TIFF image compressed into a ZIP archive. Your browser may be already set up to decompress these files. Commercial software to perform this is available from PKWARE, Inc., the company that invented the format. A web page from a group of people creating shareware or public domain software is available at Info-ZIP. The TIFFs are 150-dpi archival-quality color scans of the original forms and can be viewed by software like Corel PhotoPaint or Adobe PhotoShop.
